MOCAP EPDM Tapered Plugs --

MOCAP Tapered EPDM Plugs
Size Chart Samples

EPDM Tapered Plugs

MEP Series


MOCAP Tapered EPDM Rubber Plugs are stocked in dozens of sizes to fit your specific application. EPDM rubber product tapered plugs are chemical resistant and good to 246°C (450°F) and are reusable in many applications. Available in sizes to fit 5-40 standard thread through 5" openings, and M4 through M160 metric threaded holes.

MOCAP's line of rubber products includes silicone and EPDM rubber caps and plugsstocked in many sizes for immediate shipment.

  • Durable and Reusable
  • Sizes to Fit 1/8" to 5" holes
  • Silicone Rubber Tapered Plugs Also Available








EPDM Tapered Plugs application images

MEP Series - EPDM Tapered Plugs Mocap Tapered EPDM Plugs App1 Mocap EPDM Tapered Rubber Plugs App2 Mocap EPDM Tapered Rubber Plugs App3

MEP Series Size Chart

Part # Suggested Applications (A)
Small Diameter		 (B)
Large Diamter		 (C)
Length
mm mm mm
 KMRP.062/187 M3 5-40 8-32 1.6 4.7 19.1
 KMRP.125/250 M4 M5 10-24 12-48 3.2 6.4 25.4
 KMRP.187/343 M6 M7 M8 3/4 -20 7/16 4.7 8.7 25.4
 KMRP.250/437 M10 3/8 7/16 6.4 11.1 25.4
 KMRP.313/562 M12 M14 1/2 9/16 8.0 14.3 28.6
 KMRP.437/687 M16 5/8 11.1 17.4 25.4
 KMRP.562/750 M18 3/4 14.3 19.1 25.4
 KMRP.625/800 M20 7/8 15.9 20.3 25.4
 KMRP.750/925 M22 M24 1 19.1 23.5 25.4
 KMRP.827/1.063 21.0 27.0 28.3
 KMRP1.036/1.246 26.3 31.6 25.4
 KMRP1.187/1.437 30.1 36.5 25.4
 KMRP1.306/1.622 33.2 41.2 25.4
 KMRP1.469/1.750 37.3 44.5 25.4
 KMRP1.621/1.973 41.2 50.1 25.4
 KMRP1.881/2.198 47.8 55.1 25.4
 KMRP2.000/2.469 50.8 62.7 25.4
 KMRP2.118/2.506 53.8 63.7 25.4
 KMRP2.272/2.697 57.7 68.5 25.4
 KMRP2.437/2.953 61.9 75.0 34.9
 KMRP2.750/3.500 69.9 88.9 38.1
 KMRP3.250/4.000 82.6 101.6 38.1
 KMRP3.500/5.000 88.9 127.0 50.8
Samples

Many Sizes EPDM and Silicone Rubber Plugs in Stock for Immediate Shipment. EPDM is chemical resistant and good up to 246°C/475°F. Silicone good up to 316°C600°F.

Not Quite Sure What You Need? Want to Consider Another Type or a Different Material?
Consult MOCAP's Exclusive Application Advisor for Assistance.
