Finger Nub Vinyl Grips

FG


Vinyl Hand-Grips
MOCAP Handle Grips with Finger Nubs
  • Material: Vinyl (BLACK)
  • Ergonomic Design Allows for a Secure Hold
  • Stretches for a Snug Fit but Won't Split, Tear or Shred

FG – Product Media

Finger Nub Vinyl Grips Handle Grips with Finger Nubs Plastic Handle Grips Vinyl Hand-Grips Plastic hand grips

Size Chart Handle Grips with Finger Nubs

PrintPrint

FG Size Chart

Default Part # Description Product Range To Fit Diameter Inside Diameter
mm
Min Inside Length
mm
Max Inside Length
mm
Wall Thickness
mm
Stocked Length
mm
Box/Mini/Micro
QTY
See Prices / Buy Online
1 FG15.5S UK [FG] 15.5MM X ?MM FG 5/8" 15.5 63.5 95.3 1.6 880 176 18 Sample
2 FG18.5S UK [FG] 18.5MM X ?MM FG 3/4" 18.5 88.9 114.3 1.6 600 120 12 Sample
3 FG21.3S UK [FG] 21.3MM X ?MM FG 7/8" 21.3 101.6 114.3 1.6 360 72 8 Sample
4 FG24.4S UK [FG] 24.4MM X ?MM FG 1" 24.4 88.9 114.3 1.6 360 72 8 Sample
Wall thickness is measured approx. 6.35mm (.25 inch) from open end. Wall thickness increases slightly towards the closed end of the part
Legend:
- Add to Basket - View Price

Micropacks are only available for purchase through our online store.



Not sure what part you need? Would you like to consider another type or part, or a different material?
Consult MOCAP's Application Advisor for assistance.



Finger Nub Vinyl Grips - Information

MOCAP Dip Moulded Finger Nub Vinyl Plastic Grips not only improve appearance but also provide a secure comfortable grip on items with handles or levers. Our round finger nub vinyl grips are available in a variety materials, colours, hardness durometers (soft, semi-rigid or hard), and diameters to fit your application. Choose from our many material options including our traditional smooth & glossy vinyl plastic or rubber-like textured vinyl plastic material. Flexible but durable vinyl materials can stretch onto slightly larger dimensions for a snug fit without splitting, tearing or shredding. All MOCAP round grip materials are tough, weather resistant and attractive. Custom moulded hand grips can also be produced with minimal tooling costs. Also available: round vinyl grips to fit 4.8mm (3/16) 214.0mm (8.42") diameters.

Most vinyl plastic caps, plugs and grips can be imprinted with your company name, logo or message.

Consider MOCAP's Double Dip process which allows you to combine various colours, formulas and textures to produce a unique product and improve overall appearance.









RoHS


Diagram
Plastic hand grips
