General Purpose Plugs for BSP Threads

 0800 046 7436


General Purpose Plugs for BSP Threads

GPB


Plastic BSP Plugs with Screwdriver Slot on Cap
General Purpose Plugs for BSP Threads

GPB–Product Media

General Purpose Plugs for BSP Threads General Purpose Plugs for BSP Threads BSP Thread Plug Plastic BSP Thread Plugs British Standard Pipe Fitting Plastic BSP Plugs with Screwdriver Slot on Cap Plastic Plugs for BSP Threads General Purpose BSP Plastic Plug Caps Plastic  Plugs for BSP Threads General Purpose Plugs for BSP Threads
  • Material: PP (Polypropylene) (Red)
  • Designed to Protect BSP Threads and Fittings from Damage, Dust, Debris and Contaminants
  • Knurled Head and Slot for Easy On-Off Application

Size Chart BSP Thread Plug

GPB Size Chart

Table View
List View
Part # Description To Fit BSP Flange Thickness
mm
in
Length
mm
in
Flange OD
mm
in
Box/Mini/Micro
QTY
See Prices / Buy Online
GPB0125RD4 General Purpose Plugs for BSP Threads - GEN PURPOSE PLUG FOR BSP 1/8 THRDS, PP RED G1/8
5.1
0.200
8.9
0.350
21.1
0.830
5000 1000 100
GPB0250RD4 Plastic Plugs for BSP Threads - GEN PURPOSE PLUG FOR BSP 1/4 THRDS, PP RED G1/4
5.1
0.200
8.9
0.350
21.1
0.830
5000 1000 100
GPB0375RD4 General Purpose BSP Plastic Plug Caps - GEN PURPOSE PLUG FOR BSP 3/8 THRDS, PP RED G3/8
6.1
0.240
9.9
0.390
23.1
0.910
5000 1000 100
GPB0500RD4 Plastic Plugs for BSP Threads - GEN PURPOSE PLUG FOR BSP 1/2 THRDS, PP RED G1/2
6.1
0.240
11.9
0.470
27.9
1.100
3000 600 60
GPB0625RD4 Plastic BSP Plugs with Screwdriver Slot on Cap - GEN PURPOSE PLUG FOR BSP 5/8 THRDS, PP RED G5/8
6.1
0.240
11.9
0.470
30.5
1.200
2500 500 50
GPB0750RD4 British Standard Pipe Fitting - GEN PURPOSE PLUG FOR BSP 3/4 THRDS, PP RED G3/4
6.1
0.240
14.0
0.550
34.3
1.350
2000 400 40
GPB0875RD4 Plastic BSP Thread Plugs - GEN PURPOSE PLUG FOR BSP 7/8 THRDS, PP RED G7/8
7.6
0.300
14.0
0.550
38.1
1.500
1500 300 30
GPB1000RD4 BSP Thread Plug - GEN PURPOSE PLUG FOR BSP 1 THRDS, PP RED G1
7.6
0.300
14.0
0.550
40.6
1.600
1500 300 30
GPB1250RD4 General Purpose Plugs for BSP Threads - GEN PURPOSE PLUG FOR BSP 1-1/4 THRDS, PP RED G1-1/4
7.6
0.300
14.0
0.550
50.8
2.000
800 160 16
GPB1500RD4 General Purpose Plugs for BSP Threads - GEN PURPOSE PLUG FOR BSP 1-1/2 THRDS, PP RED G1-1/2
8.9
0.350
15.0
0.590
54.6
2.150
600 120 12
GPB2000RD4 Plastic Plugs for BSP Threads - GEN PURPOSE PLUG FOR BSP 2 THRDS, PP RED G2
8.9
0.350
15.0
0.590
66.3
2.610
400 80 8
GPB3000RD4 General Purpose BSP Plastic Plug Caps - GEN PURPOSE PLUG FOR BSP 3 THRDS, PP RED G3
10.2
0.400
19.1
0.750
94.7
3.730
150 30 3
Part # Description To Fit BSP Flange Thickness
mm
in
Length
mm
in
Flange OD
mm
in
Box/Mini/Micro
QTY
See Prices / Buy Online
Legend:
- Add to Basket - View Price

Micropacks are only available for purchase through our online store.



Not sure what part you need? Would you like to consider another type or part, or a different material?
Consult MOCAP's Application Advisor for assistance.



General Purpose Plugs for BSP Threads - Information

MOCAP General Purpose Plugs are designed for use on British Standard Pipe threads and fittings. These Threaded Plastic Plugs are ridged for ease with manual assembly, but can also be tightened with a screwdriver or hex wrench.
Protects threaded components from moisture, dust and damage during production, shipping and storage, and can also be used as masking during painting and plating. Designed to work in low-pressure testing requirements.
Our GBP Series Threaded Plugs are moulded in Red polypropylene plastic and sized to plug BSP threads from 1/8 thru 1/2.

Many Sizes of Our General Purpose Plugs for BSP Threads are Stocked for Immediate Shipment.


Most stock sizes are available in Mini-Packs when Smaller Quantities are Needed. To place an order for this product, call 0800 046 7436 or use our Contact Request Form to receive information by e-mail.
