General Purpose Plugs for Unified/Straight Threads

GPU


General Purpose Plastic UNF Plugs
General Purpose Plugs for Unified/Straight Threads

GPU–Product Media

General Purpose Plugs for Unified/Straight Threads Polypropylene Plastic Plug Caps for UNF Threads General Purpose Plastic Bolt for UNF Threads Plastic Plugs for Unified and Straight Threads General Purpose Plugs for Unified/Straight Threads General Purpose Plastic UNF Plugs Polypropylene Plastic Plug Caps for UNF Threads General Purpose Plastic Bolt for UNF Threads Plastic Plugs for Unified and Straight Threads
  • Material: PP (Polypropylene)
  • Stocked Material: PP (Red)
  • Designed to Provide Positive Seal on SAE Straight-Thread Ports
  • Features a Molded-In O-Ring Style Bead and External Lip on the Flange to Seal Out Contaminants

Size Chart General Purpose Plastic Bolt for UNF Threads

GPU Size Chart

Table View
List View
Part # Description To Fit STD Thread Length
mm
in
Stem Height
mm
in
Flange OD
mm
in
Box/Mini/Micro
QTY
See Prices / Buy Online
GPU0437-20 General Purpose Plugs for Unified/Straight Threads - GEN PURPOSE PLUG FOR 7/16-20 STR THRDS 7/16 - 20
8.6
0.340
5.3
0.210
16.8
0.660
8000 1600 160
GPU0437-24 Plastic Plugs for Unified and Straight Threads - GEN PURPOSE PLUG FOR 7/16-24 STR THRDS 7/16 - 24
8.6
0.340
5.3
0.210
16.8
0.660
8000 1600 160
GPU0500-20 General Purpose Plastic Bolt for UNF Threads - GEN PURPOSE PLUG FOR 1/2-20 STR THRDS 1/2 - 20
8.6
0.340
6.4
0.250
18.5
0.730
6000 1200 120
GPU0562-18 Polypropylene Plastic Plug Caps for UNF Threads - GEN PURPOSE PLUG FOR 9/16-18 STR THRDS 9/16 - 18
9.1
0.360
6.4
0.250
20.3
0.800
6000 1200 120
GPU0625-18 General Purpose Plastic UNF Plugs - GEN PURPOSE PLUG FOR 5/8-18 STR THRDS 5/8 - 18
9.1
0.360
6.4
0.250
22.1
0.870
5000 1000 100
GPU0750-16 General Purpose Plugs for Unified/Straight Threads - GEN PURPOSE PLUG FOR 3/4-16 STR THRDS 3/4 - 16
10.4
0.410
6.4
0.250
25.9
1.020
3000 600 60
GPU0875-14 Plastic Plugs for Unified and Straight Threads - GEN PURPOSE PLUG FOR 7/8-14 STR THRDS 7/8 - 14
13.5
0.530
6.4
0.250
29.5
1.160
2000 400 40
GPU1000-14 General Purpose Plastic Bolt for UNF Threads - GEN PURPOSE PLUG FOR 1-14 STR THRDS 1 - 14
13.5
0.530
6.4
0.250
35.1
1.380
1500 300 30
GPU1062-12 Polypropylene Plastic Plug Caps for UNF Threads - GEN PURPOSE PLUG FOR 1-1/16-12 STR THRDS 1-1/16 - 12
15.5
0.610
6.4
0.250
36.8
1.450
1000 200 20
GPU1187-12 General Purpose Plugs for Unified/Straight Threads - GEN PURPOSE PLUG FOR 1 3/16-12 STR THRDS 1-3/16 - 12
15.5
0.610
6.4
0.250
40.6
1.600
1000 200 20
GPU1313-12 Plastic Plugs for Unified and Straight Threads - GEN PURPOSE PLUG FOR 1-5/16-12 STR THRDS 1-5/16 - 12
15.5
0.610
6.4
0.250
44.2
1.740
1000 200 20
GPU1625-12 General Purpose Plastic Bolt for UNF Threads - GEN PURPOSE PLUG FOR 1-5/8-12 STR THRDS 1-5/8 - 12
15.5
0.610
6.4
0.250
55.1
2.170
700 140 14
GPU1875-12 Polypropylene Plastic Plug Caps for UNF Threads - GEN PURPOSE PLUG FOR 1 7/8-12 STR THRDS 1-7/8 - 12
15.5
0.610
6.4
0.250
62.0
2.440
600 120 12
Part # Description To Fit STD Thread Length
mm
in
Stem Height
mm
in
Flange OD
mm
in
Box/Mini/Micro
QTY
See Prices / Buy Online
Legend:
- Add to Basket - View Price

Micropacks are only available for purchase through our online store.



Not sure what part you need? Would you like to consider another type or part, or a different material?
Consult MOCAP's Application Advisor for assistance.



General Purpose Plugs for Unified/Straight Threads - Information

MOCAP General Purpose Plugs are designed for use on Unified/Straight threads and fittings. These Threaded Plastic Plugs are slotted, and feature a 12-point head for screwdriver, socket or wrench tightening.
Designed to provide a positive seal on SAE straight-threaded ports. Moulded-in O-Ring style bead seats into the bevel of the threaded opening to prevent fluid or oil leakage. When tightened , an external lip on the flange compresses against the surface to keep contaminants and debris from the part face.
Our GPU Series Threaded Plugs are moulded in Red polypropylene plastic and sized to plug threads from 1/8 thru 1/2.

Many Sizes of Our General Purpose Plugs for Unified/Straight Threads are Stocked for Immediate Shipment.


Most stock sizes are available in Mini-Packs when Smaller Quantities are Needed. To place an order for this product, call 0800 046 7436 or use our Contact Request Form to receive information by e-mail.







RoHS


Diagram
